What is KubeAtlas

KubeAtlas builds a directed dependency graph of every resource in a Kubernetes cluster — Deployments, ConfigMaps, Services, Ingresses, Gateways, HTTPRoutes, PVCs, RBAC, CRDs — and lets you query it. It answers the questions a flat kubectl get view cannot:

• "If I delete this Secret, what breaks?"
• "Which Deployments mount this ConfigMap?"
• "What's the routing path from this Ingress to a Pod?"

What it is not

• A general-purpose Kubernetes UI. Use Headlamp or Lens for that.
• A monitoring tool. Use Prometheus, Datadog, or your APM of choice.
• A GitOps tool. Use Argo CD or Flux.

KubeAtlas is the dependency graph: a focused view that complements the tools above instead of replacing them.

Project status

Current main is the unreleased v1.6 development line. Its bounded target is production operability on vanilla Kubernetes 1.34–1.36; the remaining upgrade, restore, scheduled E2E, performance, soak, runbook, and artifact gates are still planned work. Use the documentation version menu to select 1.5.2 for instructions that match the latest published artifacts.

v1.5.2 is released. The dependency graph keeps Secret references but KubeAtlas no longer lists or watches Secret objects. Defensive inputs are reduced to reference-only nodes before rule evaluation or storage, existing Tier 2 Secret rows and historical event payloads are scrubbed during migration, and snapshot history is metadata-only for every resource. The public release artifacts and production install path are verified; new installations should pin v1.5.2. See the release matrix for the evidence and the independently reviewed integration status.

v1.5.1. The v1.5.0 feature set is unchanged, but the Tier 2 installation and release lifecycle are hardened: CloudNativePG 0.22.1 is an explicit cluster-scoped prerequisite, the embedded PostgreSQL Cluster and its PVCs are retained on uninstall by default, and the release workflow publishes the pinned PostgreSQL + Apache AGE image before the Helm chart. Upgrade, database-recovery, uninstall-retention, and snapshot paths are enforced in CI.

v1.5.0. A non-breaking minor: an opt-in OpenTelemetry runtime overlay (GET /api/v1/otel/overlay, Tier 2, observed CALLS_AT_RUNTIME edges layered over the declarative graph); read-side multi-cluster RBAC visibility (F-206) keyed on a hashed bearer token, open when unconfigured; and an internal GraphStore v2 that surfaces graphstore_version on GET /api/v1/info while leaving the public HTTP API unchanged and v1alpha1 frozen. A Headlamp OTel Overlay view and the Backstage plugin at Headlamp parity ship alongside.

v1.4.0. A self-contained offline diagnostic report (kubeatlas diagnose, HTML/JSON, for air-gapped audits and CI), policy visibility (Gatekeeper Constraints and Kyverno policies surface as ENFORCES edges via runtime CRD discovery, with a new Policy view), opt-in anonymous usage telemetry (off by default, with a documented trust contract and a transparent /api/v1/telemetry/preview), and per-version API usage counters that begin tracking v1alpha1 vs v1 ahead of the v2.0 removal. A Headlamp Policy view and a GitHub Action policy-report option ship alongside.

v1.3.1 — federation cluster picker wired to the topology canvas, keyboard graph traversal, drag-anchor time-axis rail, radial menu for blast-radius depth, screen-reader announcements, Slate theme WCAG AA contrast fix, and kubectl atlas --version.

v1.3.0. Multi-cluster federation (one KubeAtlas instance attaches to N kubeconfigs and serves /api/v1/federation/*), platform-identity edges (BINDS_PLATFORM_IDENTITY for EKS IRSA / AKS Workload Identity / GKE Workload Identity), HorizontalPodAutoscaler support (new SCALES edge type), kubeatlas-action for GitHub CI, and the cartography Web UI redesign (5 runtime-switchable themes, ⌘K command palette, blast-radius mode, time-axis diff, edge-type filter presets, multi-cluster left strip).

Carried forward from earlier phases: persistent state (PostgreSQL + Apache AGE, opt-in), Rego rule packs, RBAC graph, blast radius, orphan + cycle detection, /api/v1/* GA alongside the frozen /api/v1alpha1/*, cert-manager TLS Helm integration. Defaults stay the same as v0.1.0: in-memory unless you opt in, single-replica, no built-in authentication — see the security warning before exposing the UI. The Quick Start walks through the install; the Roadmap covers what's next.

Reading order

1. Quick Start — get a graph out of a cluster (any cluster you control; kind works if you don't have one) in a few minutes.
2. Architecture — design principles and how the pieces fit together.
3. Concepts — the conceptual model (blast radius, orphans + cycles, Rego rules, API versioning).
4. Developer Guide — for contributors: prerequisites, build, test, and a worked example of adding an edge type.
5. Roadmap — where KubeAtlas is going next.
